Standard Material Combination
1 |
BODY |
A105 F6a |
A350 LF2 |
A182 F11 |
A182 F11 |
A182 F22 |
A182 F9 |
A182 F304 |
A182 316 |
A182 F304L |
A182 F316L |
4 |
GASKET |
Stainless steel + Graphoil |
Stainless steel + Graphoil |
Stainless steel + Graphoil |
Stainless steel + Graphoil |
Stainless steel + Graphoil |
Stainless steel + Graphoil |
Stainless steel + Graphoil |
Stainless steel + Graphoil |
Stainless steel + Graphoil |
Stainless steel + Graphoil |
5 |
BONNET |
A105 F6a |
A350 LF2 |
A182 F11 |
A182 F11 |
A182 F22 |
A182 F9 |
A182 F304 |
A182 316 |
A182 F304L |
A182 F316L |
6 |
STUDS |
A193 B7 |
A193 L7 |
A193 B7 |
A193 B16 |
A193 B16 |
A193 B16 |
A193 B8 |
A193 B8 |
A193 B8 |
A193 B8 |
7 |
GLAND PACKING |
To suit service conditions |
To suit service conditions |
To suit service conditions |
To suit service conditions |
To suit service conditions |
To suit service conditions |
To suit service conditions |
To suit service conditions |
To suit service conditions |
To suit service conditions |
8 |
GLAND |
A182F6a |
A182 F6a |
A182F6a |
A182 F6a |
A182F6a |
A182 F6a |
F-304 |
F-316 |
F-304L |
F-316L |
9 |
GLAND FLANGE |
A216 WCB |
A352 LCB |
A217 WC1 |
A217 WC6 |
A217 WC9 |
A217 C5 |
A351 CF8 |
A351 CF8M |
A351 CF3 |
A351 CF3M |
10 |
NUTS |
A194 2H |
A194 4 |
A194 2H |
A194 4 |
A194 4 |
A194 8 |
A194 8 |
A194 8 |
A194 8 |
A194 8 |
12 |
YOKE SLEEVE |
Al. Bronze BS1400 AB2C or Ni-resist to A439 D2 |
Al. Bronze BS1400 AB2C or Ni-resist to A439 D2 |
Al. Bronze BS1400 AB2C or Ni-resist to A439 D2 |
Al. Bronze BS1400 AB2C or Ni-resist to A439 D2 |
Al. Bronze BS1400 AB2C or Ni-resist to A439 D2 |
Al. Bronze BS1400 AB2C or Ni-resist to A439 D2 |
Al. Bronze BS1400 AB2C or Ni-resist to A439 D2 |
Al. Bronze BS1400 AB2C or Ni-resist to A439 D2 |
Al. Bronze BS1400 AB2C or Ni-resist to A439 D2 |
Al. Bronze BS1400 AB2C or Ni-resist to A439 D2 |
13 |
HANDWHEEL |
DIA536 80-55-06 OR MI 108 BM290 |
DIA536 80-55-06 OR MI 108 BM290 |
DIA536 80-55-06 OR MI 108 BM290 |
DIA536 80-55-06 OR MI 108 BM290 |
DIA536 80-55-06 OR MI 108 BM290 |
DIA536 80-55-06 OR MI 108 BM290 |
DIA536 80-55-06 OR MI 108 BM290 |
DIA536 80-55-06 OR MI 108 BM290 |
DIA536 80-55-06 OR MI 108 BM290 |
DIA536 80-55-06 OR MI 108 BM290 |
15 |
HANDWHEEL RETAINING NUT |
STEEL |
STEEL |
STEEL |
STEEL |
STEEL |
STEEL |
STEEL |
STEEL |
STEEL |
STEEL |
