SLUICE VALVES

BACK




SPECIFICATIONS
BOLTED BONNET, INSIDE SCREW & NON RISING STEM, FLANGED ENDS AS ANSI.B 16.1 CLASS 125, UNLESS OTHERWISE SPECIFIED IN THE CONTRACT.

MAX. PERMISSIBLEWRKING PRESSURE
SIZES<300 mm
13.8 bar FOR WATER SUPPLY UPTO 45°C
SIZES> 300mm< 600mm
10.3 bar FOR WATER SUPPLY UPTO 45°C

Standard Material Combination
S.No. PartName Cu. ALLOY TRIM ALL IRON
1 BODY C.I. TO EN 156 Gr. GJL200 C.I TO EN 1561 Gr. GJL200
2 BODY SEAT FACING G.M. TO EN 1982 Gr.CC491K (RENEWABLE) C.I. TO EN 1561 Gr. GJL200 (INTEGRAL)
3 WEDGE FACING G.M. TO EN 1982 Gr.CC491K (RENEWABLE) C.I. TO EN 1561 Gr. GJL200 (INTEGRAL)
4 WEDGE C.I. TO EN 1561 Gr. GJL200 C.I TO EN 1561 Gr. GJL200
5 WEDGE NUT G.M. TO EN 1982 Gr. CC491K C.I TO EN 1561 Gr. GJL200
6 STEM HT. BRASS TO IS 6912 Gr. FHTB1 CARBON STEEL TO IS 2062 Gr. B
7 BONNET GASKET COMPRESSED FIBRE TO IS 2712 Gr. C COMPRESSED FIBRE TO IS 2712 Gr. C
8 BONNET C.I. TO EN 1561 Gr. GJL200 C.I. TO EN 1561 Gr. GJL200
9 BOLTS & NUTS CARBON STEEL TO BS 916 CARBON STEEL TO BS 916
10 T-HEAD BOLTS CARBON STEEL (MIN. UTS 392/mm2) CARBON STEEL (MIN. UTS 392/mm2)
10 NUTS CARBON STEEL TO BS 916 CARBON STEEL TO BS 916
11 STUFFING BOX GASKET COMPRESSED FIBRE TO IS 2712 Gr. C COMPRESSED FIBRE TO IS 2712 Gr. C
12 STUFFING BOX C.I. TO EN 1561 Gr. GJL200 C.I TO EN 1561 Gr. GJL200
13 GLAND PACKING JUTE & HEMP TO IS 5414 OR ASBESTOS TO IS 4687 JUTE & HEMP TO IS 5414 OR ASBESTOS TO IS 4687
14 GLAND C.I. TO EN 1561 Gr. GJL200 C.I. TO EN 1561 Gr. GJL200
15 HANDWHEEL C.I. TO EN 1561 Gr. GJL200 C.I. TO EN 1561 Gr. GJL200
16 WASHER CARBON STEEL (ANY GRADE) CARBON STEEL (ANY GRADE)
17 SET SCREW OR NUT CARBON STEEL TO BS 916 CARBON STEEL TO BS 916
NOTE : The above data is subject to change without notice due to our continuing product improvement programme.


LEADER

CAST IRON SLUICE VALVES CLASS 125

CAST IRON SLUICE VALVES-14846:2000 PN1, PN1.6
