CAST STEEL Y-TYPE STRAINERS CLASS 150, 300

BACK




NOTE:-* PARTS SHALL BE APPLICABLE FOR SIZE 100mm &
ABOVE
C.S.S. 'Y' TYPE STRAINER CL-150
FLANGED END AS PER ASME B 16.5:96
TEST PRESSURE:- TESTED TO:-30 BAR (HYD)

Standard Material Combination
S.No. PartName CAST CARBON STEEL
1 BODY C.C.S. ASTMA 216 Gr. WCB
2 SCREEN S.S AISI-304 1f PERFORATION
3 CAGE FABRICATED
4 GASKET C.A.F BS 1832
5 COVER C.C.S ASTMA 216 Gr. WCB
6 BOLTS ALLOY STEEL ASTMA 193 Gr. B7
8 DRAIN PLUG S.S ASTMA 276 TYPE 410
NOTE : The above data is subject to change without notice due to our continuing product improvement programme
