 FORGED STEEL BALL VALVE-BS5351, ANSI B16.34 CLASS-800

BACK









Standard Material Combination
S.No. PartName Carbon Steel to ASTM A105 Stainless steel to ASTM type CF8 Stainless steel to ASTM type CF8M
1 BODY A105 A351 CF8 A351 CF8M
2 BODY SEAL GRAPHOIL GRAPHOIL GRAPHOIL
3 PIPE CONNECTOR A105 A351 CF8 A351 CF8M
4 BALL A276 304 A276 304 A193 B16
5 SEAT VIRGIN UNFILLED OIL FREE PTFE VIRGIN UNFILLED OIL FREE PTFE VIRGIN UNFILLLED OIL FREE PTFE
6 STEM SEAL VIRGIN UNFILLED OIL FREE PTFE VIRGIN UNFILLED OIL FREE PTFE VIRGIN UNFILLLED OIL FREE PTFE
7 GLAND SEAL VIRGIN UNFILLED OIL FREE PTFE VIRGIN UNFILLED OIL FREE PTFE VIRGIN UNFILLLED OIL FREE PTFE
8 GLAND A276 304 A276 304 A276 316
10 LEVER CARBON STEEL CARBON STEEL CARBON STEEL
11 NUTS A194 B7 A194 8 A194 8
12 STEM A276 304 A276 316 A276 316
13 BOLTS A193 B7 A193 B8 193 B8
14 STOPPER PLATE (Zn. Plated) CARBON STEEL CARBON STEEL CARBON STEEL
15 LOCKING WASHER Type 304 Type 304 Type 316
NOTE : The above data is subject to change without notice due to our continuing product improvement programme.
