 CAST STEEL FIRE SAFE BALL VALVE CLASS 150, 300 & 6

BACK



SPECIFICATIONS:
FULL BORE, SPLIT BODY,
SIDE ENTRY, BLOW OUT
PROOF STEM & FLOATING
BALL DESIGN







Standard Material Combination
S.No. PartName Carbon Steel to ASTM type WCB Stainless steel to ASTM type CF8 Stainless steel to ASTM type CF8M
1 BODY A216 Gr. WCB A351 Gr.CF8 ASTM A351 Gr CF8M
2 SEAT VIRIGIN UNFILLED OIL FREE PTFE VIRIGIN UNFILLED OIL FREE PTFE VIRIGIN UNFILLED OIL FREE PTFE
3 BALL ASTM A351 CF8 ASTM A351 CF8 ASTM A351 CF8M
4 ANTISTATIC BALL S.S. 316 SS 316 SS 316
5 SPRING BS 2056 EN 58A BS 2056 EN58A BS 2056 EN58A
6 STEM SEAL GRAPHOIL GRAPHOIL GRAPHOIL
7 GLAND PACKING GRAPHOIL GRAPHOIL GRAPHOIL
8 GLAND ASTM A276 TYPE410 ASTM A276 TYPE304 ASTM A276 TYPE316
9 DISC SPRING (Blackended) BS 970 EN 42J BS 970 EN 42J BS 970 EN 42J
10 STOPPER PLATE (Zn. Plated) IS 2062 Gr. B IS 2062 Gr.B IS 2062 Gr.B
11 STEM NUT (Zn. Plated) ASTM A194 Gr. 2H ASTM A194 Gr.8 ASTM A194 Gr.8
12 LEVER HOLDER (Bl. Plated) ASTM A216 Gr. WCB/ IS2108 Gr. BM 290 ASTM A216 Gr. WCB/ IS2108 Gr. BM 290 ASTM A216 Gr. WCB/ IS2108 Gr. BM 290
13 LOCKING WASHER S.S 304 SS 316 SS 316
14 LEVER NUT (Zn. Plated) ASTM A194 Gr8 ASTM A194 Gr8 ASTMA A194 Gr.8
15 STEM ASTM A276 TYPE410 ASTM A276 TYPE304 ASTM A276 TYPE316
16 PIN CARBON STEEL CARBON STEEL CARBON STEEL
17 LEVER PIPE ASTMA 106 Gr. B ASTM A106 Gr.B ASTM A106 Gr.B
18 GASKET STAINLESS STEEL WITH GRAPHITE STAINLESS STEEL WITH GRAPHITE STAINLESS STEEL WITH GRAPHITE
19 BODY CONNECTOR ASTM A216 Gr WCB ASTM A351 CF8 ASTM A351 CF8M
20 CAP LDPE LDPE LDPE
21 NUTS ASTM A194Gr2H ASTM A194 Gr8 ASTM A194 Gr8M
21 STUDS ASTM A193 Gr B7 ASTM A193 Gr B8 ASTM A193 Gr B8M
22 STOPPER PIN HARDENED HARDENED HARDENED
23 NAME PLATE S.S/ANODIZED ALUMINIUM S.S/ANODIZED ALUMINIUM S.S/ANODIZED ALUMINIUM
NOTE : The above data is subject to change without notice due to our continuing product improvement programme.
